DN15-DN100
PP, PPH, PPR
150psi, 232psi
EPDM, FPM
ISO5211(F03/F05/F07/F10)
Connection: ANSI socket, DIN socket, BSP thread, NPT thread, G thread
Accessories: 0.8m cable wires; bracket&screw;with manual override
Customized: Extra wires length
Rated Torque: 10Nm-2000Nm
Enclosure level: IP67
Housing material: ABS/Die-casting aluminum
Rated Voltage: DC12V、DC24V、AC24V、AC110V、AC230V、AC/DC24V、AC/DC95~265V
Modulating control mode: 0~5V、1~5V、0~10V、2~10V、0~20mA、4~20mA
Install Actuator: ON &OFF Actuator, Modulating Actuator, Failsafe capacity Actuator, RS485 Series Actuator, Intelligent on&off Actuator, Intelligent Modulating Actuator
Functions Ordered: High speed On/Off Type,Power Off Reset Type,PID Type,Nb_lot Type
Features 1 Multi-position mode can be realized
Features 2 High performance brushless motor, overheat/overload protection of internal motor.
Features 3 Service life-20000 cycles (Max:9371648 times)
What voltage does the electric actuator apply to?
Normally, MTD actuator have single voltage, 110V AC, 220VAC, 24V AC/DC, 12VDC, and wide voltage, 95-265V AC/DC.
What is the advantages of MTD electric valve compared to the traditional manual valve?
1. It can meet the requirements of most working conditions and the working conditions that ordinary valves cannot be used; can be run in automated systems, remote control ,RS 485 control, wireless control, highly intelligent, so as to save labor cost and operation cost.
2. It has both on-and-off and regulation functions, with valve position indication and output;
3. Applicable to almost all media, with the maximum viscosity of 600mm²/s (centistokes);
4. High temperature resistance, chemical corrosion resistance, wear resistance and durability, water hammer impact resistance;
5. With manual function, it can be equipped with hexagon wrench, hand wheel type, and the actuator can be equipped with explosion-proof type in explosion-proof environment ;
6. Two way circulation, simple operation, stable control and long service life.
What material are MTD Motorized Valves Made of?
The housing of MTD electric actuator is made of ABS or Die casting aluminum, and the valve is made of plastic(uPVC, CPVC, PPH, PPR, PVDF), brass, stainless steel(304,316), ductile iron.
Plastic Ball Valves
The uPVC valve body is durable and cost-effective. It is light, compact, non-toxic, wear resistance and easy to install, disassemble and maintain. Additionally, our MTD chemical plastic valves which is made of CPVC, PPH, PPR, PVDF can be used in complex condition that have corrosive media such as salt water or acids.
Applicable fields of electric valve
Industrial sewage/Water treatment device, Sea and brackish water desalination, Ultra-filtration and disinfection, Can/bottle system, Beer brewing and beverage technology, chemical industry, Fluid mixing device, Food industry, Concrete and cement industry, Vacuum technology, Medical equipment, Swimming pools and spa, Industrial lakes and aquariums, Process control and other fields.
Connection: ANSI socket, DIN socket, BSP thread, NPT thread, G thread
Accessories: 0.8m cable wires; bracket&screw;with manual override
Customized: Extra wires length
Rated Torque: 10Nm-2000Nm
Enclosure level: IP67
Housing material: ABS/Die-casting aluminum
Rated Voltage: DC12V、DC24V、AC24V、AC110V、AC230V、AC/DC24V、AC/DC95~265V
Modulating control mode: 0~5V、1~5V、0~10V、2~10V、0~20mA、4~20mA
Install Actuator: ON &OFF Actuator, Modulating Actuator, Failsafe capacity Actuator, RS485 Series Actuator, Intelligent on&off Actuator, Intelligent Modulating Actuator
Functions Ordered: High speed On/Off Type,Power Off Reset Type,PID Type,Nb_lot Type
Features 1 Multi-position mode can be realized
Features 2 High performance brushless motor, overheat/overload protection of internal motor.
Features 3 Service life-20000 cycles (Max:9371648 times)
What voltage does the electric actuator apply to?
Normally, MTD actuator have single voltage, 110V AC, 220VAC, 24V AC/DC, 12VDC, and wide voltage, 95-265V AC/DC.
What is the advantages of MTD electric valve compared to the traditional manual valve?
1. It can meet the requirements of most working conditions and the working conditions that ordinary valves cannot be used; can be run in automated systems, remote control ,RS 485 control, wireless control, highly intelligent, so as to save labor cost and operation cost.
2. It has both on-and-off and regulation functions, with valve position indication and output;
3. Applicable to almost all media, with the maximum viscosity of 600mm²/s (centistokes);
4. High temperature resistance, chemical corrosion resistance, wear resistance and durability, water hammer impact resistance;
5. With manual function, it can be equipped with hexagon wrench, hand wheel type, and the actuator can be equipped with explosion-proof type in explosion-proof environment ;
6. Two way circulation, simple operation, stable control and long service life.
What material are MTD Motorized Valves Made of?
The housing of MTD electric actuator is made of ABS or Die casting aluminum, and the valve is made of plastic(uPVC, CPVC, PPH, PPR, PVDF), brass, stainless steel(304,316), ductile iron.
Plastic Ball Valves
The uPVC valve body is durable and cost-effective. It is light, compact, non-toxic, wear resistance and easy to install, disassemble and maintain. Additionally, our MTD chemical plastic valves which is made of CPVC, PPH, PPR, PVDF can be used in complex condition that have corrosive media such as salt water or acids.
Applicable fields of electric valve
Industrial sewage/Water treatment device, Sea and brackish water desalination, Ultra-filtration and disinfection, Can/bottle system, Beer brewing and beverage technology, chemical industry, Fluid mixing device, Food industry, Concrete and cement industry, Vacuum technology, Medical equipment, Swimming pools and spa, Industrial lakes and aquariums, Process control and other fields.
